BLADE 150CC
BLADE 150 cc
|
ENGINE |
|
|
Certification |
EPA approved |
|
Engine type |
4-stroke, Single-Cylinder, Air/Oil-cooled |
|
Displacement |
149.6cc |
|
Horse Power |
7.45kw(7000r/min) 10HP |
|
Valve Configuration |
OHV |
|
Compression ratio |
9.0:1 |
|
FUEL SYSTEM |
|
|
Fuel Delivery System |
Fuel Pump Carburetor |
|
Choke System |
Automatic |
|
Fuel capacity |
9.5L (2.1 Gallon) |
|
DRIVETRAIN |
|
|
Driveline Type |
2X4 |
|
Final Drive |
Chain-drive |
|
Transmission |
Constantly Variable Transmission |
|
Gear Selection |
Forward & Reverse Single Speed |
|
ELECTRICAL SYSTEM |
|
|
Forward Lights |
Headlights-High & Low Beam LED LIGHT |
|
Rear Lights |
Brake Lights & Left/Right Signal lights |
|
Starting system |
Electric start |
|
Ignition system |
C.D.I |
|
SUSPENSION / BRAKES |
|
|
Suspension Front |
Adjustable Double A-arm optional |
|
Suspension Rear |
Dual Shock Swing arm |
|
Brakes Front |
Front Dual Hydraulic Disk |
|
Brakes Rear |
Rear Single Axle Hydraulic Disk |
|
Steering |
Rock and pinion steering |
|
TIRES |
|
|
Front Tread |
1020mm (40.2 in) |
|
Rear Tread |
1040mm (38.0in) |
|
Front & Rear tire size |
22x8-10 / 22x10-10 |
|
MISC |
|
|
Top speed |
55km/h |
|
Dry weight |
245kg (540 lbs.) |
|
Gross weight |
280kgs(617lbs) |
|
Wheelbase |
1860mm (71.0in) |
|
Vehicle dimension (L×W×H) |
2450x1220x1397mm (96.5x 48.0x55.0 in) |
|
Packing size |
2290x1300x815mm |
|
Ground clearance |
152mm (6in) |
|
Safety |
Driver & Passenger Seat belts/ Driver and Passenger safety net restraints. |
