Engine System | |
Engine Type | ZM125cc, Single Cylinder, 4-Stroke, Air Cooled |
Displacement | 124 ml |
Max Power | 6.2(1±10%)/7000(1±5%) kw/r/min |
Max Torque | 9.0(1±10%)/5000(1±5%) N.m/r/min |
Compression Ratio | 9.6:1 |
Shift Type | 4 Speed Simi Automatic |
Start Type | Kick Start |
Carburetor | PZ26 Jingke Carburetor |
Drive Train | #428,14/41T |
Size Data | |
L x W x H | 64.1" * 29.5" * 41.3" |
Wheel Base | 42.3" |
Tires | FT: 60/100-14 - RR: 80/100-12 |
Seat Height | 29.6" |
Ground Clearance | 13.5 |
Fuel Capacity | 3.5 L |
Frame/Suspension/Brake/Wheel system | |
Frame | Cradle Type Steel Tube Frame |
Front Fork |
Non-Adjustable Inverted 700mm Forks, Travel - 4.3" Tube - 1.2" |
Rear Shock | Coil Spring shock - 10.8" , Travel - 1.6" |
Swing-Arm | Steel - 14.9" |
Handle Bar | Steel |
Wheels | Steel 1.6 x 17" / 1.85 x 14" Rims, Cast Hubs |
Front Brake | Single Piston Caliper, 210mm Disc |
Rear Brake | Single Piston Caliper, 190mm Disc |
Exhaust | Stainless Steel Header Pipe, Haxagon Aluminum Silencer |
Packing and Loading | |
Packing Size | 54.5" * 14.7" * 29.7" |
N.W/KG | 145.5 LBS |
G.N/KG | 172 LBS |
